Leitor de código de barras de fio de venda quente com recursos avançados
This COMS imaging mode scanner features a USB interface suitable for a variety of electronic devices. It scans barcodes using technologies such as lasers and cameras, transmitting the acquired data to computers or other smart devices, thus enabling rapid processing and application of information. This feature makes barcode scanners play an irreplaceable role in multiple fields. which 1D&2D QR codes support both paper and screen.
Descrição
COMS Imaging Sensor：
This feature makes the wire barcode scanner play an irreplaceable role in multiple fields, which support both 1D and 2D QR codes on paper and screens. The COMS mode can achieve instant recognition and interpretation of QR codes upon proximity, significantly enhancing work efficiency. Moreover, we can provide various styles to meet your needs.
| Sensor de imagem | CMOS | |
|---|---|---|
| Taxa de resolução | 1280*800 (exposição total) | |
| Interface | USB (HID, CDC) | |
| Read Code System | 2D | MicroQR, PDF417, QR Code, DataMatrix, Aztex, Maxicode |
| 1D | Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E,Interleaved 2 of 5, ITF-6, ITF-14, ISBN, Code 93,UCC/EAN-128, GS1 Databar, Matrix 2 of 5, Code 11,Industrial 2 of 5, Standard 2of 5, Plessey, MSI-Plessey, etc |
|
| Reading accuracy | 5mil | |
| Iluminação | LED branco | |
| Rotational sensitivity | Spin | 360° |
| Lean | ±50° | |
| Deflection | ±50° | |
| Symbol contrast | ≥ 30% | |
| Ângulo de campo | Nível | 49° |
| Vertical | 37° |
|
| Ambiente de aplicação | EAN 13 | 55mm-230mm (13mil) |
| QR | 35mm-170mm (15mil) | |
| Matriz de dados | 40mm-115mm (20mil) | |
| QRCode (Wechat) | 40mm-410mm(32mil) | |
| Dimensão (mm) | 42 x 48,5 x 21 (C x L x A) | |
| Consumo atual | 300mW | |
| Entrada de tensão | 5 VCC | |
| Atual | Corrente máxima | 70mA @5V |
| Corrente típica | 60mA @5V | |
| Luz ambiente | 0 ~ 100.000 LUX | |
| Cabo USB | Cabo USB, é usado para conectar o mecanismo de leitura ao host receptor de informações |
